MATCH PP86DSP 8x70W kanals Plug&PlayHigh End DSP forsterker i lite format

6 590,-

MATCH er nye spesialtilpassede produkter fra tyske Audiotec Fischer (Brax, Helix)
The crown of the Plug & Play amplifier series – with its vast performance capabilities on an ultra-small footprint, the new PP 86DSP outshines everything that came before it. With its huge range of functions, when it comes to sensitivity, it also ushers in a new era, thanks to Audiotec Fischers unique Class HD Technology. The combination of state-of-the-art digital amplifier technology and a dynamically controlled switched power supply reduces heat generation and power consumption to an absolute minimum. But thats not all – an impressive eight separate and freely configurable amplifier channels roaring with power enable even sophisticated system configurations with a single amplifier.
Proprietary Class HD Technology for peerless sensitivity and minimal heat generation
8 separate configurable amplifier channels for maximum flexibility
Extremely powerful DSP with virtually limitless sound adjustment options freely configurable via PC- Tool software
56-bit DSP technology and 24-bit AD/DA converter from BurrBrown
Optical S/PDIF input 6 – 192 kHz with an integrated sample rate converter
USB-on-board for direct connection to a PC
Freely configurable 2-channel PreOut for the connection of additional amplifiers
Aux input with automatic or manual switchover
Start/stop capable down to 6 volts supply voltage
Latest D/A converter-controlled P³S power supply technology with "ECO Mode"
Plug jack for optional cable remote control, functionality configurable via PC software
State-of-the-art SMD technology for a more compact design and maximum reliability
Six-layer printed circuit boards in multilayer technology for the best possible power and signal trans mission
Utviklet og produsert i Tyskland
8 kanals effektforsterker med kraftig DSP (56bit)
Kobles til via bilens orginale ledningsnett, ingen klipping av kabler
Oppsett til ulike biler kan lastes ned og oppdateres via SD kort
Mulighet for å koble til en passiv basshøyttaler
Innganger: 4 x høynivå, 1 x Aux,1 x Optical
Aux inngang for feks MP3 spiller, Navi enhet, iPod
5V mini USB utgang lading
RMS Effekt 4 Ohm: 8 x 55W
RMS Effekt 2 Ohm: 8 x 70W
Stabil 2 Ohm stereo
Fritt konfigurerbar DSP via USB
14 + 8 bands parametrisk Equalizer for front og bak kanaler
Valgbare senter frekvenser
Valgbar Q faktor fra 0,1 - 15
Tidskorrigering uavhengig for alle kanaler med 0,02msec (=0,7cm) step
Høy / lav og bandpass filter for hver kanal opptil 24dB/oktav
Dynamisk begrenser for hver kanal for maksimal høyttalerbeskyttelse
Frekvensrespons 20 Hz - 22 kHz
Signal/støy forhold > 100 dB
Total harmonisk forvrenging THD < 0,02%
Dempingsfaktor > 100
Powertilkoblinger: iso
Høyttalertilkoblinger: iso
Spiller selv om spenningen synker helt til 6V (feks ved start av motor)
Sikring 2 x 25A
Mål (H x B x L): 44mm x 185mm x 164mm

~

MATCH PP86DSP 8x70W kanals Plug&Play High End DSP forsterker i lite format

Tilbehør

Alternativer

Artikler

Antall artikler funnet:

MATCH PP86DSP 8x70W kanals Plug&Play High End DSP forsterker i lite format

MATCH PP86DSP 8x70W kanals Plug&Play High End DSP forsterker i lite format

MATCH PP86DSP 8x70W kanals Plug&Play High End DSP forsterker i lite format

MATCH PP86DSP 8x70W kanals Plug&Play High End DSP forsterker i lite format

MATCH PP86DSP 8x70W kanals Plug&Play

High End DSP forsterker i lite format

Varenr:122470

Alt. varenr: PP86DSP

6 590,-

-+

Bestillingsvare

Du er 5 000 kroner unna å få FRI FRAKT!

Beskrivelse

MATCH er nye spesialtilpassede produkter fra tyske Audiotec Fischer (Brax, Helix)
The crown of the Plug & Play amplifier series – with its vast performance capabilities on an ultra-small footprint, the new PP 86DSP outshines everything that came before it. With its huge range of functions, when it comes to sensitivity, it also ushers in a new era, thanks to Audiotec Fischers unique Class HD Technology. The combination of state-of-the-art digital amplifier technology and a dynamically controlled switched power supply reduces heat generation and power consumption to an absolute minimum. But thats not all – an impressive eight separate and freely configurable amplifier channels roaring with power enable even sophisticated system configurations with a single amplifier.
Proprietary Class HD Technology for peerless sensitivity and minimal heat generation
8 separate configurable amplifier channels for maximum flexibility
Extremely powerful DSP with virtually limitless sound adjustment options freely configurable via PC- Tool software
56-bit DSP technology and 24-bit AD/DA converter from BurrBrown
Optical S/PDIF input 6 – 192 kHz with an integrated sample rate converter
USB-on-board for direct connection to a PC
Freely configurable 2-channel PreOut for the connection of additional amplifiers
Aux input with automatic or manual switchover
Start/stop capable down to 6 volts supply voltage
Latest D/A converter-controlled P³S power supply technology with "ECO Mode"
Plug jack for optional cable remote control, functionality configurable via PC software
State-of-the-art SMD technology for a more compact design and maximum reliability
Six-layer printed circuit boards in multilayer technology for the best possible power and signal trans mission
Utviklet og produsert i Tyskland
8 kanals effektforsterker med kraftig DSP (56bit)
Kobles til via bilens orginale ledningsnett, ingen klipping av kabler
Oppsett til ulike biler kan lastes ned og oppdateres via SD kort
Mulighet for å koble til en passiv basshøyttaler
Innganger: 4 x høynivå, 1 x Aux,1 x Optical
Aux inngang for feks MP3 spiller, Navi enhet, iPod
5V mini USB utgang lading
RMS Effekt 4 Ohm: 8 x 55W
RMS Effekt 2 Ohm: 8 x 70W
Stabil 2 Ohm stereo
Fritt konfigurerbar DSP via USB
14 + 8 bands parametrisk Equalizer for front og bak kanaler
Valgbare senter frekvenser
Valgbar Q faktor fra 0,1 - 15
Tidskorrigering uavhengig for alle kanaler med 0,02msec (=0,7cm) step
Høy / lav og bandpass filter for hver kanal opptil 24dB/oktav
Dynamisk begrenser for hver kanal for maksimal høyttalerbeskyttelse
Frekvensrespons 20 Hz - 22 kHz
Signal/støy forhold > 100 dB
Total harmonisk forvrenging THD < 0,02%
Dempingsfaktor > 100
Powertilkoblinger: iso
Høyttalertilkoblinger: iso
Spiller selv om spenningen synker helt til 6V (feks ved start av motor)
Sikring 2 x 25A
Mål (H x B x L): 44mm x 185mm x 164mm

~
