Ubiquiti Unifi Switch Gen2 Pro 24-Port 24 x RJ45(16xPoE+,8xPoE++), 2xSFP+, 450W

Ubiquiti Unifi Switch Gen2 Pro 24-Port

24 x RJ45(16xPoE+,8xPoE++), 2xSFP+, 450W

Varenr:120116

Alt varenr:USW-Pro-24-POE

9 995,-ink. mva

Bestillingsvare

Beskrivelse

USW-Pro-24-POE Gen 2, AC/DC, Internal, 450W, (24) 10/100/1000 RJ45 Ports, (2) 1/10G SFP+, 442.4 x 285.4 x 43.7 mm

Second-Generation UniFi Switching
We’ve redesigned our UniFi Switches from the ground up.

Near Silent Cooling
Our new airflow design reduces the need for fan usage.

Powerful Hardware and Software
UniFi Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3* switching capabilities.

Redundant Power System
UniFi SmartPower RPS, USP-RPS, is our PSU failover system.

Power Supply Failure
In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device.

UniFi SmartPower
One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

Touchscreen Display
The 1.3" touchscreen display allows easy monitoring and quick troubleshooting.

Spesifikasjoner

Data transmission

Forwarding rate

65,472 Mpps

Jumbo frames support

Y

Static route

Y

Switching capacity

88 Gbit/s

Throughput

44000 Mpps

Design

Certification

CE, FCC, IC

Form factor

1U

LED indicators

Activity, Link, PoE, Speed, System

Product colour

Silver

Rack mounting

Y

Reset button

Y

Management features

Switch layer

L2/L3

Switch type

Managed

Network

10G support

Y

Auto MDI/MDI-X

Y

Auto-sensing

Y

Cable types supported

Cat5

Ethernet LAN data rates

10, 100, 1000

Flow control support

Y

Full duplex

Y

Networking standards

IEEE 802.3af, IEEE 802.3at

Port mirroring

Y

Spanning tree protocol

Y

VLAN support

Y

Operational conditions

Operating relative humidity (H-H)

10 - 90 %

Operating temperature (T-T)

-5 - 40 °C

Package dimensions

Depth

12,5 cm

Gross Weight

5,6 kg

Height

52 cm

Width

39,5 cm

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

24

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Installed SFP+ modules quantity

2

Power connector

AC-in jack

Power

AC input frequency

50/60 Hz

AC input voltage

100 - 240 V

DC input voltage

52 V

Input current

7.69 A

Number of power supply units

1

Power consumption (max)

30 Watt

Power supply included

Y

Power over Ethernet (PoE)

Y

Power over Ethernet (PoE) power per port

64 Watt

Power over Ethernet plus (PoE+) ports quantity

16

Total Power over Ethernet (PoE) budget

400 Watt

Product dimensions

Depth (product,cm)

28,54 cm

Height (product,cm)

4,37 cm

Net Weight (Product, kg)

4,3 kg

Product Width

44,24 cm

Security

Authentication type

IEEE 802.1x, RADIUS

DHCP features

DHCP server

Vendor information

Brand Name

Ubiquiti Networks

Warranty

2 År
