Physical Port

• 8-port 10/100/1000BASE-T Gigabit Ethernet RJ45 copper
• 4-port IEEE 802.3at/af PoE Injector (Port-1 to Port-4)

Power over Ethernet

• Complies with IEEE 802.3af/at Power over Ethernet end-span PSE
• Up to 4 ports of IEEE 802.3af/802.3at devices powered
• Supports PoE Power up to 30.8 watts for each PoE port
• Each port supports 53V DC power to PoE powered device
• 60-watt PoE budget
• Auto detects powered device (PD)
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m with standard mode, 200m with extended mode

Switching

• Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
• Flow control for full duplex operation and back pressure for half duplex operation
• IEEE 802.1Q VLAN transparency
• Hardware DIP switch for “Standard” and “Extend” mode selection; the “Extend” mode features 30-watt PoE transmit distance of 200m at speed of 10Mbps (Only for Port1 – Port4)

Hardware

• 8.5-inch desktop size, 1U height, rack mountable
• LED indicators for system power, per port PoE ready and PoE activity, speed, Link/Act
• Fanless design
• Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
