Rich, punchy bass with low distortion

Using the Kelton method*, the CM-510ST filters out unwanted mid and high-range frequencies and includes our newly developed Vortex Bass Accelerator technology to deliver pure, smooth bass with a quick response.

* The Kelton method extracts bass sound from a speaker by acoustically cutting out mid-to-high-range sounds. This is achieved by emitting the sound from a duct in a chassis sealed to the front and back of the unit.

Hardware

Loudspeaker Type

Kelton method subwoofer

Rigging and Hardware

20 × M8 threaded mounting points on side

Enclosure

Black: Wood w/Polyuretane paintWhite: Wood w/water-based paint

System data

Frequency response (- 10 dB, Typical)

45 Hz - 150 Hz

Sensitivity (1W/1m)

95 dB (half space)

Nominal Impedance

8 O

Loudspeaker data

Power Handling (RMS/Program)

200 W / 400 W* IEC60268-5

Transformer taps

70 V: 200 W / 100 W / 50 W / 25 W100 V: 200 W / 100 W / 50 W

Maximum SPL

124 dB (peak, half space)* Calculated from the power handling and sensitivity

Driver Configuration

10" (250 mm) cone

Connectors

Euroblock (4 pin) × 1 (input: +/-, loop-thru: +/-)

Dimensions / Weight

Dimensions ( W x H x D)
