MATCH PP 10W-Q 4 x 3 ohmElement For Match PP62 og 86

1 490,-

You did not find the type of enclosure sub you are looking for? – If none of the MATCH Plug & Play enclosure subs fits in your car with respect to shape and / or size, then you have the chance to build your "personalized" version by yourself. Therefore, we offer the single woofers of our Plug & Play series, which are 100 % identical to the drivers that are used in the pre-loaded variants. As long as you choose the net volume and port tuning frequency according to the installation instructions, we guarantee the same acoustical performance as our "standard" subwoofers.
10” / 250 mm Plug & Play subwoofer with quad voice coil for compact vented enclosures
Extremely stiff hand-scooped paper cone for maximum sound pressure
Double ventilated voice-coil for minimum compression effects
Powerful magnet for compact-sized vented enclosures
Optimized for the perfect interaction with MATCH Plug & Play amplifiers
Connection terminal for MATCH subwoofer cable (PP-SC) included in delivery
Power RMS / max. P 300 / 600 Watts
Impedance Z 4 x 3 Ohm
Resonance frequency Fs 29 Hz
Total Q factor Qts 0.35
Equivalent air volume Vas 46 L
Force factor B*I 23.5 Tm
Efficiency 1 W / 1 m SPL 87 dB
Cone area Sd 333 cm²
Moving mass Mms 98 g
Voice coil diameter ø 50.8 mm
Outer diameter ø 265 mm / 10.43"
Installation diameter ø 232 mm / 9.13"
Installation depth 128.5 mm / 5.06"
Vented box Net volume 18 L
Port diameter ø 70 mm / 2.75"
Port area 28 cm²
Port length 33 cm / 13"
Port tuning frequency Fb 39 Hz
Lower limiting frequency (-3dB) 36 Hz
DSP settings:
- Highpass: Self-Define; crossover frequency 33 Hz; Q factor 1.3
- Lowpass: Butterworth; 24 dB/octave; crossover frequency 80 - 100 Hz

MATCH PP 10W-Q 4 x 3 ohm Element For Match PP62 og 86

Tilbehør

Alternativer

Artikler

Antall artikler funnet:

MATCH PP 10W-Q 4 x 3 ohm Element For Match PP62 og 86

MATCH PP 10W-Q 4 x 3 ohm Element For Match PP62 og 86

MATCH PP 10W-Q 4 x 3 ohm

Element For Match PP62 og 86

Varenr:122564

Alt. varenr: PP10W-Q

1 490,-

-+

Bestillingsvare

Du er 5 000 kroner unna å få FRI FRAKT!

Beskrivelse

You did not find the type of enclosure sub you are looking for? – If none of the MATCH Plug & Play enclosure subs fits in your car with respect to shape and / or size, then you have the chance to build your "personalized" version by yourself. Therefore, we offer the single woofers of our Plug & Play series, which are 100 % identical to the drivers that are used in the pre-loaded variants. As long as you choose the net volume and port tuning frequency according to the installation instructions, we guarantee the same acoustical performance as our "standard" subwoofers.
10” / 250 mm Plug & Play subwoofer with quad voice coil for compact vented enclosures
Extremely stiff hand-scooped paper cone for maximum sound pressure
Double ventilated voice-coil for minimum compression effects
Powerful magnet for compact-sized vented enclosures
Optimized for the perfect interaction with MATCH Plug & Play amplifiers
Connection terminal for MATCH subwoofer cable (PP-SC) included in delivery
Power RMS / max. P 300 / 600 Watts
Impedance Z 4 x 3 Ohm
Resonance frequency Fs 29 Hz
Total Q factor Qts 0.35
Equivalent air volume Vas 46 L
Force factor B*I 23.5 Tm
Efficiency 1 W / 1 m SPL 87 dB
Cone area Sd 333 cm²
Moving mass Mms 98 g
Voice coil diameter ø 50.8 mm
Outer diameter ø 265 mm / 10.43"
Installation diameter ø 232 mm / 9.13"
Installation depth 128.5 mm / 5.06"
Vented box Net volume 18 L
Port diameter ø 70 mm / 2.75"
Port area 28 cm²
Port length 33 cm / 13"
Port tuning frequency Fb 39 Hz
Lower limiting frequency (-3dB) 36 Hz
DSP settings:
- Highpass: Self-Define; crossover frequency 33 Hz; Q factor 1.3
- Lowpass: Butterworth; 24 dB/octave; crossover frequency 80 - 100 Hz
