Cypress Konverter SDI > DVI

2.97Gbps Max 100-300m

Alt varenr:CLUX-SDI2DVIA
3 071,-ink. mva
SDI to DVI Converter
The SDI to DVI Converter allows SD, HD and 3G-SDI signals to be shown on DVI display. This means that it is now easier for professionals to distribute and extend their SDI signal while giving the ability to display work on DVI display. Additionally, the built-in stereo Audio Out will allow the user to enjoy perfectly synchronized video and audio.
Smart Home/Luxury House
Smart building or any Smart AV Installation System
Converting a 3G SDI camera signal to DVI signal
Supports SD-SDI, HD-SDI and 3G-SDI input signals with auto-detection
Shows SDI source on DVI display
SDI interface operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s
Supports SDI input distance up to 100M (3G-SDI), 200M (HD-SDI), or 300M (SD-SDI)
Converts SDI signal to DVI:
SD-SDI (SMPTE 259M-C) → 480i/576i
HD-SDI (SMPTE 292M) → 720p@50/59.94/60, 1080i@50/59.94/60
3G-SDI (SMPTE 424M/425M-AB) → 1080p@23.98/24/25/29.97/30/50/59.94/60, 1080psF@23.98/24/25/29.97/30
Supports SDI input modes:
SD-SDI (SMPTE 259M-C, at bitrates of 270 Mbit/s)
HD-SDI (SMPTE 292M, at bitrates of 1.485 Gbit/s and 1.485/1.001 Gbit/s)
3G-SDI (SMPTE 424M/425M-AB, at bitrates of 2.970 Gbit/s and 2.970/1.001 Gbit/s)
NOTE: Cable tested with Belden 1694A. Operating distance may vary if used with another type of cable.
